AJ-2205 Medical Ventilator surgery room ICU equipment

FOB Reference Price:Get Latest Price
US $2,000-2,500 / Units | 1 Unit/Units (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Type:
Respiratory Equipments Accessories
Brand Name:
ANJUE
Model Number:
AJ-2205
Place of Origin:
China (Mainland)
Power:
AC220V+22V 50HZ+1HZ UPS, Storage battery
Ventilation mode:
SIPPV,SIMV,PCV,SPONT,MANUAL,CPAP
Tidal Volume:
50-1500 mL
Rate:
1--99bpm
I:E:
4:1--1:8
Supply Ability
Supply Ability:
1000 Unit/Units per Month
Packaging & Delivery
Packaging Details
standard package for the international transporation
Port
Shanghai/ Shenzhen/others
Lead Time :
within 10 days upon receipt of payment

Specifications

1. Medical Ventilator
2. good performance
3.UPS,Battery
4. 5.7 inch high clear display
5.CE and ISO

1. Medical Ventilator
2. good performance
3.UPS,Battery
4. 5.7 inch high clear display
5.CE and ISO



medical ventilator AJ-2205






Main technical parameters

Display                     Colored LCD, touch screen setting, big font display, free changeable angles of views

Various ventilation modes       SIPPV,SIMV,PCV,SPONT,MANUAL,CPAP

Ventilation parameters         PEEP,SIGH,IRV,Inspiratory platform

Tidal Volume                 50-1500 mL

Rate                         1~99bpm

SIMVrate                     2~20bpm

I:E                         4:1~1:8

Trigger sensitivity             -1.0~1.0kPa

PEEP                       0~25cmH2O

Pressure control               3~50cmH2O

SIGH                 1.5 times the inspiratory time (60 ~ 120 times adjustable)

Inspiratory platform           0~50%

Oxygen concentration         48%~100%

Pressure limit               5~60cmH2O

Parameters for ventilation monitoring     tidal volume, ventilation volume, IPPV rate, total respiratory rate, peak pressure of airway, pressure - time waveform, flow rate - time waveform, inspiratory trigger pressure, Inspiratory platform, Oxygen concentration, battery capacity

Safety alarm system

Airway pressure alarm                 upper limit setting range   0.3~6.0 kPa

lower limit setting range   0.2~5.0 kPa

Per-minute ventilation volume alarm     upper limit setting range 3.0~30L/min

lower limit setting range 1.0~10L/min

Vt alarm                           upper limit setting range 10~2000ml

lower limit setting range 0~1800 ml

Sustained high-pressure alarm       it will give alarm when stress have consistently been higher than 2.5 kPa

Suffocation alarm                 it will give sound and light alarm if there is no tidal volume input for 15 seconds

Power failure alarm

Power                           AC 220V±10%     50Hz±1Hz

                               UPS, Storage battery

Battery under-voltage alarm

Power loss alarm

Intubation off alarm

Heated humidifier
